Product Description:
The Q341F-16C DN150 Worm Gear Operated Ball Valve is a heavy-duty industrial valve designed for precise flow control and reliable shutoff in pipelines. Featuring a full bore design and carbon steel construction, it is ideal for use in petroleum, chemical, water treatment, and other industrial applications.

Key Features:

• Model: Q341F-16C

• Size: DN150 (6 inch)

• Pressure Rating: PN16 (16 bar)

• Body Material: WCB (Cast Carbon Steel)

• Ball Material: Stainless Steel or Chrome-Plated Steel (customizable)

• Seal Material: PTFE / RPTFE

• Operation: Worm Gear Drive

• Connection Type: Flanged ends (as per GB, ANSI, or DIN standard)

• Structure: Floating Ball / Two-piece / Full Bore

• Working Temperature: -29°C to +180°C (depending on seal material)

• Applicable Media: Water, Oil, Gas, Steam, etc.

Product Advantages:

• Precise manual operation through a durable worm gear mechanism

• Excellent sealing performance with low torque operation

• Anti-static design and blow-out proof stem for enhanced safety

• Corrosion and wear-resistant internal components

• Long service life and easy maintenance

Applications:

• Oil & Gas

• Chemical Processing

• Power Plants

• Water Supply and Drainage Systems

• Industrial Pipelines

Optional Customizations:

• Electric or pneumatic actuator available

• Special coatings or trims for corrosive media

• ANSI, DIN, JIS standard flanges upon request
